PV580 Series Solar Pumping Inverter

The PV580 series IP65 solar pump inverter can operate in extreme temperatures and features an optimized MMP algorithm and DC/AC power input, which makes the PV580 Series automatic inverter the perfect solution for agricultural irrigation problems, daily water use, and desert management in areas with electricity storage and water storag.

Get a Quote

Data Download

Feature Specification Application Download

1.Solve the problems of agricultural irrigation, daily water use, and desert management in areas with no electricity and water shortage

2.Widely used in various AC asynchronous pumps and synchronous pumps

3.IP65 design, high protection level outdoor installation model

4.Compatible with DC/AC power input

5.Optimized MPPT algorithm, efficiency is over 99%

6.Operating temperature range: -25~ 60 degrees

7.Adopt natural cooling method, low noise

8.GPRS remote monitoring of real-time operation status, real-time start and stop (optional)

9.Excellent performance, large water output

10.Fully automatic unattended operation, with perfect overcurrent, overvoltage, output phase loss protection, short circuit, overheating and other protection functions

11.The power model below 2.2KW is equipped with a built-in booster module as standard, which meets the requirements of low-voltage operation and can reduce the number of solar panels, thereby reducing costs

·Application

PV580 series solar pump inverters allow autonomous systems without human supervision. Frecon solar VFDs start the pump when the conditions (irradiation) are suitable and always obtain the maximum power from the solar panels, thanks to the function of Maximum Power Point Tracking (MPPT).

As a professional solar pump inverter manufacturer, Frecon provides perfect solar pump drive solutions for water use in particular areas. Frecon automatic solar pump inverters can solve the problems of agricultural irrigation, daily water use, and desert management in areas with no electricity and water shortage. PV580 series can pump water during dry and sunny weather in regions that need it most, offering a longer lifespan and plenty of energy.

PV580 Series Solar pump Inverter EN 202408 V1.5.pdf
