1. Pure sine wave solar inverter
2. Built-in MPPT solar charger controller
3. Configurable AC/Solar charger priority
4. Configurable output source priority
5. Compatible to mains voltage or generator power
6. With complete short-circuit, over-voltage,under-voltage, overload protection, etc.
| Model | SP500-3KW-24L | SP500-3KW-24H | SP500-5KW-48H |
| Rated power | 3000VA | 3000VA | 5000VA |
| AC input | |||
| Rated input voltage | 220/230VAC | ||
| Operating voltage range | 170~280VAC(For personal computers)；90~280VAC(For home applications) | ||
| Frequency range | 50Hz/60Hz(Auto sensing) | ||
| Output | |||
| Rated output voltage(VAC) | 230VAC | ||
| Surge power | 6000VA | 6000VA | 1000VA |
| Effffciency(peak) | 94% | ||
| Transfer time | 10ms(For personal computers) ; 20ms(For home applications) | ||
| Battery & AC charger | |||
| Battery voltage | 24VDC | 48VDC | |
| Floating charge voltage | 27VDC | 54VDC | |
| Overcharge protection | 33VDC | 63VDC | |
| Maximum charging current | 80A | 60A | |
| Solar charger | |||
| Maximum PV array power | 2000W | 4000W | 6000W |
| MPPT range @ operating voltage | 30~100VDC | 120~450VDC | 120~450VDC |
| Maximum PV array open circuit voltage | 100VDC | 495VDC | 495VDC |
| Maximum charging current | 80A | ||
| Physical | |||
| Dimension D*W*H(mm) | 103*280*378 | 110*309*355 | 110*309*415 |
| Net weight(kg) | 6.8 | 7.3 | 9.6 |
| Communication interface | USB/RS485/WiFi | ||
| Operating environment | |||
| Humidity | 5%-95% Relative humidity (non-condensing) | ||
| Operating temperature | -10°C~50°C | ||
| Storage temperature | -15°C~60°C | ||
